Miscible Gas Displacements


     Often gas injection is called miscible or immiscible.  This section illustrates important aspects of a miscible displacement of Wasson oil at reservoir conditions.  The photographs are from microvisual experiments conducted at Shell Development Company in 1984.

     This  illustrates the miscible like displacement of Wasson oil by CO2 at 1,350 psig (9,380 kPa), a pressure just above the critical point of CO2.  The CO2 and oil are clearly not miscible in this photograph, yet recovery in a MMP experiment was 94 percent..  What has happened at this pressure is that a third phase (called the middle liquid) has formed that spreads between the CO2 (upper liquid) and the oil (lower liquid).  Some pores, such as the one on the right side of the photograph appear to be completely filed with the middle liquid.  This phase is a mixture of CO2 and very light, colorless hydrocarbons that only is observed in relatively cool (42°C) reservoirs like Wasson.  The phase is also only reported for CO2 in a small pressure and composition range.  At higher pressures or temperatures that phase disappears.   This phase apparently lowers the interfacial tension between the oil and the CO2 enough that oil recovery is high.


Miscible Three Phase Displacement at 1,350 psig (9.38 Mpa) Pressure

Miscible Three Phase Displacement


     The next photograph shows a fully developed miscible displacement at 2,000 psig (13.90 Mpa).  The photograph shows a light colored band of oil (highlighted with an arrow in the direction of the flow) that is fingering through darker, bypassed oil.  What has happened at this pressure is that the CO2 has become so enriched in C3 to C10 hydrocarbons that it is totally miscible with the oil.   The enriched phase has liquid densities, so  all fluids are called liquids. With continued injection, the concentration of light hydrocarbons in the miscible phase decreases.  Then, the fluid is no longer miscible with the oil and the “lower-liquid, ”  a heavy, asphaltene-like phase begins to precipitate.  This is shown in the third photograph.  The dark dots are the lower-liquid (oil).  This phase continues to precipitate and eventually its saturation is high enough that the fluid spreads between the CO2 and water as shown in the fourth figure.  However, the lower liquid also wets the surface of the microvisual model so that foam lamella (indicated again by arrows) form.  This phenomenon is known as gas-oil foam and may be responsible for the injectivity reduction reported in projects like Wasson.


Developed Miscible Displacement

Miscible Gas Displacement_Developed Miscible Displacement

Later In Developed Miscible Displacement

Very Late in a Miscible Displacement

Miscible Gas - Later in Development

Miscible Gas - Very Late in Miscible Displacement
